Main Engine Power

110 kw . 1500 d./dk

...........................................................................................................................................................................................

Cutting speed engine power ( Up- Down)

11 kw . 1500 d/dk

...........................................................................................................................................................................................

Number of Blade

80

...........................................................................................................................................................................................

Number of stroke

96 d./dk

...........................................................................................................................................................................................

Block-cutting dimensions

Max 3300x2000x2100 mm

...........................................................................................................................................................................................

Cutting thickness dimensions

Min.16 mm.-max. Free

...........................................................................................................................................................................................

Block holder

2 x 1.5 kw . 1400 d./dk

...........................................................................................................................................................................................

Transfer Car

1 x 1.5 kw. 1400 d./dk

...........................................................................................................................................................................................

Working Feature

Cradle arm slide

...........................................................................................................................................................................................

Cutting system

Elevator system (Lifting the block)

Elevator Gear Box

4-point modular controlled gear box, and the return of the magnetic sensor is controlled by the screw shaft.

...........................................................................................................................................................................................

For block breaks in the laser switches

Standart

...........................................................................................................................................................................................

Mounting Space

4340x12825x4885 mm

...........................................................................................................................................................................................

Max. water in

800 lt./dk

...........................................................................................................................................................................................

Machine safety

Volant + v handles, wagon up-down safety switches

...........................................................................................................................................................................................

General control

Plc system

...........................................................................................................................................................................................

Emergency rescue

To be able to completly stop the moving in 30 sec.

...........................................................................................................................................................................................

Failure control

Vibration and limit control at 18 points

...........................................................................................................................................................................................

Machine Equipment

2 x block and 1 x transfer car

...........................................................................................................................................................................................

Total weight

55000 kg
